Characteristics:
Good ability to assemble and disassemble for several times without damage.
Could be lifted, fixed and combined freely.
Heatproof and waterproof.
Cost saving and convenient transportation (Each 4 container house can be loaded in one standard container)
Service life can reach up to 10 - 15 years
We can provide the service of installation, supervision and training by extra.
Technical Parameter of standard prefabricated house:
Wind resistance: Grade 11(wind speed≤111.5km/h)
Earthquake resistance: Grade 7
fire proof:B2 grade
Dimensions and Weight:
Inner length /external length :5.81m/6.06m
Inner width /external width: 2.188m/2.438
Inner height/external height:2,410m/2.591m
Weight: 2000kg per unit
Steel framework:
Material: Light steel structure, steel material Q235
Surface working: sand blasting, epoxy basic painting 55μm thick, final vinyl acrylic painting 55μm thick
Fittings: 8 standard container corner mould fittings PVC standard rainwater pipe
Forklift openings: size 100*250mm, distance is 1200mm
Floor:
Floor structure: Girder made of 4mm steel. The purlin is square tube dimension 60x40x1.5mm.
Warm proof Insulation layer: 75mm rock wool
Floor: 15mm thick plywood panel for general room; 20mm thick cement board for WC and kitchen
1.5mm PVC floor leather for living rooms floor; 1.5mm anti-slip aluminum board for toilet floor.
Permitted loading: 2.0KN/m2
Coefficient of thermal conductivity: K=1.1 W/ (m·K)
Ceiling:
Roof exterior layer: 1.2mm stamping steel plate,epoxy painting
Warm proof insulation filling: 75mm rock wool between wooden purlins;
Inner wainscot: 9mm MDF laminated decorative panel or 10mm glass magnesium fire-proof board
Permitted live loading: 0.5 KN/m2
Coefficient of thermal conductivity: K=0.55 W/ (m·K)
Roof water drain: 4 PVC rainwater pipes in the corner pillars, diameter 50mm
Walls
Panel width: 1150mm; panel total thickness: 75mm
External layer: Galvanized and painted (29μm) color steel sheet 0.5mm
Internal layer: Galvanized and painted (29μm) color steel sheet 0.5mm.
Warm proof insulation filling: 75mm EPS or rock wool or 50mm PU panel
Insulation density: EPS is 12kg/ m3;rock wool is 120kg/ m3;PU is 45kg/ m3
Permitted loading: 0.6KN/m2
Coefficient of thermal conductivity: K=0.442 W/ (m·K)
Door:
External door: sandwich panel door with opening dimension 850*2100mm, furnished with a cylinder lock with 3keys. Doorframe is made of aluminum, 50mm thick EPS insulation foam.
Windows:
Window material: PVC, white color, dimension 1130*1000mm, glass thickness: 3mm, aluminum alloy edge cover, sliding window with fly screen.
Or PVC windows with rolling shutter.
Electrical & Water system fittings
Electrical fittings option:
Voltage: 110~220V, 50~60Hz,
European standard or Chinese standard sockets (usually 3 pcs)
Switch: single control switch or double control (usually 1 pcs)
Distribution box (usually 1 pcs): with 32A breaker protector and 10A breaker protector
Double tube fluorescent light (usually 2 pcs)
Main Power Cables: copper core 2.5-4 mm2
Light Cables: copper core 1.5 mm2
All the cables with PVC or copper electric raceway
Water system fittings option:
Water drain pipe, PPR pipe, diameter 16-20mm, connection fittings are made of copper, life span over 10 years.
Exhaust fan or air exchange hole, size 250mm*250mm made of steel or PVC
Sanitary ware and cookware
Closestool: ceramic, with pipes and installation fittings
Urinal: ceramic, with pipes and installation fittings
Wash basin: ceramic, with post, faucet, pipes and installation fittings
Bath room
Bathtub: glass fiber reinforced plastics
Shower head
Shower base
Cabinets: eco-friendly materials, 15mm-18mm thickness
Work flats countertop: surell stone/stainless steel
Basin: stainless steel basin
Water pipe: PVC or stainless steel pipe
Why Choose Lida Container for Site Camp Solution?
There are many advantages to modular camp construction for site camps including:
1, Good ability to assemble and disassemble for several times without damage.
2, Could be lifted, fixed and combined freely.
3, Heatproof and waterproof.
4, Cost saving and convenient transportation (Each 4 container house can be loaded as one standard shipping container)
5,Service life can reach up to 15 - 20 years
6,We can provide the service of installation, supervision and training by extra.
